Product details
Voltage: AC220V, 50 / 60Hz
Rated power: 1500 watts
Lamp Specifications: HMI 1200W / S
Color: two color plates: 10 color +35 kinds of mixed colors + blank, half color effect, do two-way variable speed rainbow effect
Pattern: a fixed pattern disk: 5 fixed pattern film + blank, the pattern with a jitter function; a rotating pattern disk: 5 replaceable rotation pattern film + blank; do two-way variable speed rotation effect
Prism: prism, prism, semi-trapezoidal mirror, semi-cylindrical mirror and atomization mirror + blank, do two-way variable speed rotation effect
Focus: Linear focus
Zoom: 13 ° -28 ° (double magnifying glass)
Dimming: 0-100% linear dimming
Light strobe: independent two-piece strobe (1-12 times per second high-speed strobe effect)
Aperture: 5-100% linear adjustment
Light body scanning: running smooth, automatic return to correct function, adjustable speed, with 16Bit precision adjustment)
Scanning range: Horizontal 450 °, vertical 270 °
Cut light: with color + XY + pattern + prism cutting function
Cooling system: forced convection cooling
Control: DMX 512, three-core interface
Channel: Standard mode: 16; Extended mode: 18
Display: LED digital display
Protection class: IP20, built-in overheating and triggering high voltage protection
Net weight: 51Kg
Gross Weight: Carton: 59Kg; Air Box: 81Kg
Light body size: length 495 × width 400 × height 770 (mm)
Packing size: carton: length 620 × width 605 × height 895 (mm)
Airline Box: Length 590 × Width 490 × Height 990 (mm)
